    We have threads for many different types of vessels and one for any kind of vessel -Ship Spotters and Maritime Image Thread- which was meant for single images of ships, boats and anything Maritime.

    Not to clutter up these threads I'll create one for detailed picture of vessels and their machinery, equipment and accommodations for those who like that sort of things.

    Starting with a modern Offshore Construction Support Vessel, the Normand Clough. (She has been featured here before, in posts 390 and 394)

    Here she is as seen in Chiwan, China two weeks ago:




    One of two ROVs permanently carried on board:


    The FRC ready to launch:


    Proof of identity:

  • #2
    Re: Details of ships and boats

    The 250 m.t. SWL Offshore Crane:




    With wire enough on the drum to reach 3,000 m. below surface:

    Comment


    • #3
      Re: Details of ships and boats

      The bridge was featured in the earlier postings, but here is an over view of the aft manouvre and DP Operation position:
      Last edited by ombugge; October 26th, 2011, 12:07.

      Comment


      • #4
        Re: Details of ships and boats

        She is equipped with several positioning systems, besides dual DGPS
        Here is the HiPap for acoustic signals from transponders on wellheads etc.:


        Taut Wire sensor for use as source if no acoustics isavailable:


        Fan Beam for close proximity surface positioning:


        All of it controlled from this panel:

        Comment


        • #5
          Re: Details of ships and boats

          She also carry a "portable" 16-men Saturation spread and an Air Dive spread on deck, but that was outside my scope of work.
          Here is the Rescue Chamber though:

          No Hyperbaric Life Boat on board.

          Comment


          • #6
            Re: Details of ships and boats

            Life boats for 120 person on either side:


            One was lowered to test the On-load release:




            Comment


            • #7
              Re: Details of ships and boats

              The life boats are backed by another 100% coverage in Life Rafts on either side:


              The Helicopter deck is also a good help if evacuation of the full complement of 120 persons should be required:

              (Or just evacuation of non-essential personnel in case of approaching Typhoon etc.)

              The Helicopter Lounge on top of the Bridge is comfortable for waiting passengers:

              Comment


              • #8
                Re: Details of ships and boats

                Let's have a look at the other facilities available for the crew and client personnel.

                Ship's office:


                With a comfortable corner for small and informal meetings:


                For more formal meetings there is a large Conference Room:

                Comment


                • #9
                  Re: Details of ships and boats

                  Clients have their own spacious Offices:


                  And there is separate Control Rooms for each of the work size ROVs carried permanently on board:


                  Comment


                  • #10
                    Re: Details of ships and boats

                    But it is not all work and no recreation.
                    The Mess Room is spacious but does not seat all 120 persons at the same time:


                    Food is an important part of life for people working 12 hour shifts for weeks on end:

                    Comment


                    • #11
                      Re: Details of ships and boats

                      The Galley:


                      Scullery:


                      Provision Store sufficient for 30 days without re-supply:




                      Temperature in the Chillers and Freezers are recorded:
                      Last edited by ombugge; October 26th, 2011, 13:01.

                      Comment


                      • #12
                        Re: Details of ships and boats

                        There is also three Recreation Rooms. One designated for smokers:





                        Those with sharp eyes and local knowledge can probably see where the pictures on the wall comes from.

                        After all that good food, it is time for some exercise:

                        Comment


                        • #13
                          Re: Details of ships and boats

                          There are some 2-men cabins for Client's workers, but usually occupied by personnel on opposite shifts:


                          All Crew members and Senior Personnel has single cabins:


                          And all cabins have toilet and shower in-situ:

                          Comment


                          • #14
                            Re: Details of ships and boats

                            Change Room for everybody to change from work cloths to clean cloths before entering the accommodations:


                            And a Laundry Room, where the coveralls are washed before the next shift:

                            Comment


                            • #15
                              Re: Details of ships and boats

                              In case anybody should get sick or hurt, there is a fully equipped Hospital, with an Examination Bench:


                              Two bunks:


                              And even a Bath Tub:

                              For the present assignment the vessel carries two qualified Doctors from SOS International on board at all time.

                              That will have to do for today. Tomorrow I'll take you on a tour below deck, incl. the Engine Room and the Thruster compartments etc.
